Odometer Gears
Electronic Units - Odometer Gears

MECHANICAL GEARS CLICK HERE

z3 seat bushing

Z3 Seat Bushings
$30/both seats — Kit includes eight parts which is enough to fix both seats in the car.

Odometer Gears

E-39 Headlight Adjusters (2000-2003 Halogen or Xenon)
$85/side — Kit includes both male plastic parts that are broken in your headlight and a tool to remove the broken ball in the female side.
Good for either left or right sides. Made from 20% glass filled Delrin.
E39 Headlight Adjusters FAQ (PDF)

Odometer Gears

E36 Reclining Seat Gear (White)
$40/each — Recline Drivers side all years
Passenger seats from 1993-1997.

Getting to the gear FAQ

Odometer Gears

E36 Reclining Seat Gear (Green)
$40/each — Recline Passengers side 1992, 1998-99.


Getting to the gear FAQ

Odometer Gears

E36 Reclining Seat Gear (Pink)
$40/each — Bottom Seat adjustment gear. Same in both seats

Getting to the gear FAQ

E31 seat gear

E31 840/850 Seat Gears- Made to Order

Odometer Gears



E1, E2, E3 Gear Set (Electronic VDO Units)
The "E1" gear will press on with your thumb. Take a pair of wire/side cutters and squeeze firmly on the brass fitting on the drive shaft. It should slide right off. This gear will be a press fit over the plain shaft.

E1 or the drive gear is a standard 12 tooth gear.
E2 is also a standard gear and will be 48 x 12.
E3 will be a standard 48 outside and could be 12, 13, 14, 17, 19 tooth on the inside.

$65/set — Save $10 when you buy the whole set.
Please include a tooth count for the inside gear of E3, (12, 13, 14, 17, 19)

Inner tooth count for E3

Please include a tooth count for the inside gear of E3.
(12, 13, 14, 17, 19 teeth)

E1 - (12 tooth gear)

E2 - 48x12

E3 - 48x(12,13,14,17,19)
Inner tooth count for E3

Inner tooth count for E3

Order individual gears here. It is highly recommended you order the entire set.

Odometer Gears

Motometer Units for E30/R/K series Motorcycles
These units were found on several years of  3 series BMW's. Look on the curcuit board to verify which unit you have. The tooth counts are below.

Motormeter #1 12 teeth

Motormeter #2 44x16

Motormeter #3 40x22

Motormeter #4 35x22


$85/set — Save $15 when you order the whole set.

E30 BMW US Spec
motometer#1 12
motometer#2 44x16
motometer#3 40x22
motometer#4 35x22

Asian/Euro Spec E30's;
R and K series Motocycles

motometer#1 12
motometer#2 44x16
motometer#3 40x28
motometer#4 28x22

Asian/Euro Spec E30's;
R and K series Motocycles
Series 2
motometer#1 12
motometer#2 44x17
motometer#3 38x23
motometer#4 33x23
